Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | Q8F1BXXG12E |
| Color | Green |
| Current Rating | 20 mA |
| IP Rating | IP67 |
| Lamp Size | 5 mm |
| Lamp Type | LED |
| Length | 1.332" (33.85mm) |
| Life | 100000 hrs. |
| Mounting Hole Size | 0.315 in. |
| Mounting Type | Threaded |
| Shop By | Factory Choice |
| Standards | UL |
| Supply Voltage | 12 VDC |
| Temperature Rating | -40 to 85 C |
| Termination | Solder |
| Type | General Purpose |
| UPC Code | 5056112066989 |
| Warranty | 3 Year Warranty |
Overview
LED Indicators, 8mm Mount, 12/24Vdc & 220Vac, Flush Black Chrome Bezel
5mm Colored diffused epoxy lens
Maximum panel thickness 7mm
Solder lug/faston terminals
