Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Body Style | Rectangular |
| Connection Type | Screw |
| Contact Configuration | 2-wire AC, NO or NC |
| Contact Rating | 400 mA at 250V |
| Current, Switching | 400 mA |
| Height | 1.57 Inch |
| Input Voltage | 35-250V |
| Length | 4.64 Inch |
| Measurement Range | 15 mm |
| Mounting Type | Bracket/DIN Rail Flush |
| Output | NO/NC |
| Primary Type | Inductive Proximity Sensors |
| Series | |
| Shielding | Shielded |
| Supply Voltage | 35-250 VAC |
| Termination | Screws |
| UPC Code | 782113134109 |
| Weight | .63 Pound |
| Width | 1.57 Inch |
Overview
These Cutler-Hammer Sensors from Eaton's electrical business feature PBT resin housings for high resistance to corrosion. The housing is sized to offer a direct replacement for standard limit switches. The unique sensing head is factory assembled for top sensing, but can be easily converted in the field to any one of four side sensing positions. Models are available with sensing ranges from 15 mm to 40 mm. The sensors can be wired for N.O. or N.C. operation.
